CAP ALUM 22UF 20% 400V RADIAL
ESG226M400AL4AA is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 22UF 20% 400V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can.
In Stock: 8,352
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 1.35Ohm @ 100kHz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 170 mA @ 120 Hz |
| Ripple Current @ High Frequency | 272 mA @ 10 kHz |
| Impedance | 1.35 Ohms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.512" Dia (13.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPM2V220MHD1TN | Nichicon | CAP ALUM 22UF 20% 350V RADIAL | 90% | View |
| MAL215266229E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22UF 20% 400V RADIAL | 80% | View |
| UVZ2F220MHD | Nichicon | CAP ALUM 22UF 20% 315V RADIAL | 74% | View |
| UAQ2D220MPD | Nichicon | CAP ALUM 22UF 20% 200V RADIAL | 62% | View |
| MAL214068229E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22UF 20% 63V RADIAL | 56% | View |
| 63YXM22MEFRTA6.3X11 | Rubycon | CAP ALUM 22UF 20% 63V RADIAL | 53% | View |
Submit your RFQ for ESG226M400AL4AA and get a quote within 24 hours.
