CAP ALUM 680UF 20% 100V SNAP
ELG687M100AQ1AA is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 680UF 20% 100V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can - Snap-In.
In Stock: 5,749
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 680 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.2 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.392 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ELXV101EC3681MM40S | United Chemi-Con | CAP ALUM 680UF 20% 100V RADIAL | 87% | View |
| EY1J681MP51225E | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 73% | View |
| ELXZ350ELL681MJ30S | United Chemi-Con | CAP ALUM 680UF 20% 35V RADIAL | 70% | View |
| 25YXH680MEFCG412.5X16 | Rubycon | CAP ALUM 680UF 20% 25V RADIAL | 68% | View |
| 35ZL680MEFCG412.5X20 | Rubycon | CAP ALUM 680UF 20% 35V RADIAL | 64% | View |
| ELXZ160ETD681MJ16S | United Chemi-Con | CAP ALUM 680UF 20% 16V RADIAL | 57% | View |
Submit your RFQ for ELG687M100AQ1AA and get a quote within 24 hours.
