CAP ALUM 10000UF 50V SCREW
ALS36H103D3C050 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 10000UF 50V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 50 V, package / case Radial, Can - Screw Terminals.
In Stock: 13
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 10000 µF |
| Tolerance | -10%, +30% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 24mOhm @ 120Hz |
| Lifetime @ Temp. | 11000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 11.7 A @ 120 Hz |
| Ripple Current @ High Frequency | 15.6 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.500" (12.70mm) |
| Size / Dimension | 1.375" Dia (34.93mm) |
| Height - Seated (Max) | 3.125" (79.38mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
Submit your RFQ for ALS36H103D3C050 and get a quote within 24 hours.
