CAP ALUM 51000UF 20% 63V SNAP
ALC80G513FP063 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 51000UF 20% 63V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 63 V, package / case Radial, Can - Snap-In - 5 Lead.
In Stock: 5,337
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 51000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 11mOhm @ 100Hz |
| Lifetime @ Temp. | 9000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 16.83 A @ 100 Hz |
| Ripple Current @ High Frequency | 19.59 A @ 10 kHz |
| Impedance | 9 mOhms |
| Lead Spacing | 0.984" (25.00mm) |
| Size / Dimension | 1.772" Dia (45.00mm) |
| Height - Seated (Max) | 4.213" (107.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 5 Lead |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ALC80C513FP063 | KEMET | CAP ALUM 51000UF 20% 63V SNAP | 100% | View |
| ALC80E513FP063 | KEMET | CAP ALUM 51000UF 20% 63V SNAP | 100% | View |
| ALC80H513FP063 | KEMET | CAP ALUM 51000UF 20% 63V SNAP | 100% | View |
| EKMH500VND503MBA0U | United Chemi-Con | CAP ALUM 50000UF 20% 50V SNAP | 84% | View |
| ALC80F473EL040 | KEMET | CAP ALUM 47000UF 20% 40V SNAP | 69% | View |
| ALC80E473EL040 | KEMET | CAP ALUM 47000UF 20% 40V SNAP | 69% | View |
Submit your RFQ for ALC80G513FP063 and get a quote within 24 hours.
