KNB1540 U01 20% 440V L9 R15
16544-06 is a Film Capacitors manufactured by Iskra. KNB1540 U01 20% 440V L9 R15. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 100°C, voltage rating - dc 1000V (1kV), package / case Radial, Can.
In Stock: 5,848
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 0.01 µF |
| Tolerance | ±20% |
| Voltage Rating - AC | 440V |
| Voltage Rating - DC | 1000V (1kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Size / Dimension | - |
| Height - Seated (Max) | 0.236" (6.00mm) |
| Termination | Terminal Block |
| Lead Spacing | 0.591" (15.00mm) |
| Applications | General Purpose |
| Ratings | - |
| Features | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| F17723104200 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 10000PF 20% 1KVDC RAD | 100% | View |
| MKP1839310635 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 10000PF 10% 630VDC AXL | 86% | View |
| MKP1839310633R | Vishay Beyschlag/Draloric/BC Components | CAP FILM 10000PF 630VDC AXIAL | 86% | View |
| R46KI21004001M | KEMET | CAP FILM 10000PF 20% 560VDC RAD | 86% | View |
| 73615-22 | Iskra | KNB2520 U01 20% 250V L30 R15 | 84% | View |
| BFC237086103 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 10000PF 5% 100VDC RAD | 56% | View |
Submit your RFQ for 16544-06 and get a quote within 24 hours.
