IC GATE DRVR HALF-BRIDGE 44PLCC
IR2131JTRPBF is a PMIC - Gate Drivers manufactured by Infineon Technologies. IC GATE DRVR HALF-BRIDGE 44PLCC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 150°C (TJ), voltage - supply 10V ~ 20V, package / case 44-LCC (J-Lead), 32 Leads.
In Stock: 3,419
| Attribute | Value |
|---|---|
| Product Status | Active |
| Driven Configuration | Half-Bridge |
| Channel Type | Independent |
| Number of Drivers | 6 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 10V ~ 20V |
| Logic Voltage - VIL, VIH | 0.8V, 2.2V |
| Current - Peak Output (Source, Sink) | 250mA, 500mA |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Rise / Fall Time (Typ) | 80ns, 40ns |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 44-LCC (J-Lead), 32 Leads |
| Supplier Device Package | 44-PLCC, 32 Leads (16.58x16.58) |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| IR2131STRPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 28SOIC | 100% | View |
| IRS2108STRPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 8SOIC | 85% | View |
| L6390D | STMicroelectronics | IC GATE DRVR HALF-BRIDGE 16SO | 81% | View |
| 2EDL05I06PJXUMA1 | Infineon Technologies | IC GATE DRVR HALF-BRIDGE DSO14 | 80% | View |
| FAN7384MX | onsemi | IC GATE DRVR HALF-BRIDGE 14SOP | 77% | View |
| IR2112STRPBF | Infineon Technologies | IC GATE DRVR HI/LOW SIDE 16SOIC | 72% | View |
Submit your RFQ for IR2131JTRPBF and get a quote within 24 hours.
