IDFW80C65D1XKSA1
IDFW80C65D1XKSA1
IDFW80C65D1XKSA1 is a Diodes - Rectifiers - Single manufactured by Infineon Technologies. IDFW80C65D1XKSA1. Key specifications: mounting type Through Hole, package / case TO-247-3.
In Stock: 126
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Diode Type | Standard |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Current - Average Rectified (Io) | 74A (DC) |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 40 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 73 ns |
| Current - Reverse Leakage @ Vr | 40 µA @ 650 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | PG-TO247-3-AI |
| Operating Temperature - Junction | -40°C ~ 175°C |
Frequently Asked Questions
IDFW80C65D1XKSA1 is a Diodes - Rectifiers - Single manufactured by Infineon Technologies. IDFW80C65D1XKSA1
The mounting type of IDFW80C65D1XKSA1 is Through Hole.
The package type of IDFW80C65D1XKSA1 is TO-247-3.
