LOW SIDE DRIVERS
2ED24427N01FXUMA1 is a PMIC - Gate Drivers manufactured by Infineon Technologies. LOW SIDE DRIVERS. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TA), voltage - supply 5V ~ 20V, package / case 8-SOIC (0.154", 3.90mm Width) Exposed Pad.
In Stock: 1,019
| Attribute | Value |
|---|---|
| Product Status | Active |
| Driven Configuration | Low-Side |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 5V ~ 20V |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | 10A, 10A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | - |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | PG-DSO-8-900 |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MP1923GS-Z | Monolithic Power Systems Inc. | IC GATE DRVR HALF-BRIDGE 8SOIC | 93% | View |
| MP1923GRE-P | Monolithic Power Systems Inc. | IC GATE DRVR HALF-BRIDGE 10QFN | 93% | View |
| MPQ1923GRE-AEC1-Z | Monolithic Power Systems Inc. | IC GATE DRVR HALF-BRIDGE 10QFN | 93% | View |
| MP1923GR-P | Monolithic Power Systems Inc. | IC GATE DRVR HALF-BRIDGE 8VDFN | 93% | View |
| MPQ1923GRE-AEC1-P | Monolithic Power Systems Inc. | IC GATE DRVR HALF-BRIDGE 10QFN | 93% | View |
| UP1966E | EPC | IC GATE DRVR HALF-BRIDGE 12WLCSP | 86% | View |
Submit your RFQ for 2ED24427N01FXUMA1 and get a quote within 24 hours.
