IC HALF BRIDGE GATE DRIVER 650V
2ED2109S06FXUMA1 is a PMIC - Gate Drivers manufactured by Infineon Technologies. IC HALF BRIDGE GATE DRIVER 650V. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TA), voltage - supply 10V ~ 20V, package / case 8-SOIC (0.154", 3.90mm Width).
In Stock: 8,965
| Attribute | Value |
|---|---|
| Product Status | Active |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 1 |
| Gate Type | IGBT, N-Channel MOSFET |
| Voltage - Supply | 10V ~ 20V |
| Logic Voltage - VIL, VIH | 1.1V, 1.7V |
| Current - Peak Output (Source, Sink) | 290mA, 700mA |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 650 V |
| Rise / Fall Time (Typ) | 100ns, 35ns |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | PG-DSO-8-53 |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 2ED21094S06JXUMA1 | Infineon Technologies | IC HALF BRIDGE GATE DRIVER 650V | 100% | View |
| IRS21091STRPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 8SOIC | 89% | View |
| L6393D | STMicroelectronics | IC GATE DRVR HALF-BRIDGE 14SO | 89% | View |
| IRS2109SPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 8SOIC | 89% | View |
| IRS21094SPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 14SOIC | 89% | View |
| L6393DTR | STMicroelectronics | IC GATE DRVR HALF-BRIDGE 14SO | 89% | View |
