FIXED IND 250UH 4A 89 MOHM TH
1538M07 is a Fixed Inductors manufactured by Hammond Manufacturing. FIXED IND 250UH 4A 89 MOHM TH. Key specifications: mounting type Through Hole, package / case Radial, Horizontal Cylinder, current rating (amps) 4 A, size / dimension 0.810" Dia x 1.620" L (20.57mm x 41.15mm).
In Stock: 39
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 250 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 4 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 89mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | - |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Horizontal Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.810" Dia x 1.620" L (20.57mm x 41.15mm) |
| Height - Seated (Max) | - |
Submit your RFQ for 1538M07 and get a quote within 24 hours.
