LED DRIVER CC AC/DC 125-280V 540
FSP150-SZAE(070)DG is a LED Drivers manufactured by FSP Technology Inc.. LED DRIVER CC AC/DC 125-280V 540. Key specifications: operating temperature -40°C ~ 50°C (With Derating), voltage - output 125 ~ 280V, current - output (max) 700mA, size / dimension 8.62" L x 2.68" W x 1.53" H (219.0mm x 68.0mm x 38.8mm).
In Stock: 1,032
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Constant Current |
| Topology | AC DC Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 108VAC |
| Voltage - Input (Max) | 305VAC |
| Voltage - Output | 125 ~ 280V |
| Current - Output (Max) | 700mA |
| Power (Watts) | 150 W |
| Voltage - Isolation | 500 V |
| Dimming | Analog, PWM |
| Features | OTP, OVP, SCP |
| Ratings | IP67 |
| Operating Temperature | -40°C ~ 50°C (With Derating) |
| Efficiency | 92% |
| Termination Style | Wire Leads |
| Size / Dimension | 8.62" L x 2.68" W x 1.53" H (219.0mm x 68.0mm x 38.8mm) |
| Approval Agency | CE, cULus |
| Standard Number | - |
Submit your RFQ for FSP150-SZAE(070)DG and get a quote within 24 hours.
