DC DC CONVERTER 12V 1W
PUC2412S1B is a DC DC Converters manufactured by Flex Power Modules. DC DC CONVERTER 12V 1W. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 100°C (With Derating), package / case 4-SIP Module, current - output (max) 84mA.
In Stock: 69
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 5V |
| Voltage - Input (Max) | 24V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 84mA |
| Power (Watts) | 1 W |
| Voltage - Isolation | 6 kV |
| Applications | ITE (Commercial) |
| Features | Adjustable Output |
| Operating Temperature | -40°C ~ 100°C (With Derating) |
| Efficiency | 80% |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
| Size / Dimension | 0.78" L x 0.28" W x 0.45" H (19.7mm x 7.1mm x 11.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | cURus, IEC, UL |
| Standard Number | 62368-1 |
Submit your RFQ for PUC2412S1B and get a quote within 24 hours.
