FFP04S60STU
RECTIFIER DIODE
FFP04S60STU is a Diodes - Rectifiers - Single manufactured by Fairchild Semiconductor. RECTIFIER DIODE. Key specifications: mounting type Through Hole, package / case TO-220-2.
In Stock: 1,271
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Diode Type | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Current - Average Rectified (Io) | 4A |
| Voltage - Forward (Vf) (Max) @ If | 2.6 V @ 4 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 25 ns |
| Current - Reverse Leakage @ Vr | 100 µA @ 600 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-2 |
| Supplier Device Package | TO-220AC |
| Operating Temperature - Junction | -65°C ~ 150°C |
Frequently Asked Questions
FFP04S60STU is a Diodes - Rectifiers - Single manufactured by Fairchild Semiconductor. RECTIFIER DIODE
The mounting type of FFP04S60STU is Through Hole.
The package type of FFP04S60STU is TO-220-2.
Yes, FFP04S60STU is listed as Obsolete. Consider requesting a quote for alternative parts.
