HALF BRIDGE BASED MOSFET DRIVER
FAN5009MPX is a PMIC - Gate Drivers manufactured by Fairchild Semiconductor. HALF BRIDGE BASED MOSFET DRIVER. Key specifications: mounting type Surface Mount, operating temperature 0°C ~ 125°C (TJ), voltage - supply 10V ~ 13.5V, package / case 8-VDFN Exposed Pad.
In Stock: 167,782
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Driven Configuration | Half-Bridge |
| Channel Type | Synchronous |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 10V ~ 13.5V |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| Current - Peak Output (Source, Sink) | - |
| Input Type | Inverting, Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 15 V |
| Rise / Fall Time (Typ) | 40ns, 20ns |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-VDFN Exposed Pad |
| Supplier Device Package | 8-MLP (5x6) |
Submit your RFQ for FAN5009MPX and get a quote within 24 hours.
