8995151521
95 EFD CORE SET
8995151521 is a Ferrite Cores manufactured by Fair-Rite Products Corp.. 95 EFD CORE SET. Key specifications: material 95, tolerance ±25%.
In Stock: 1,900
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Core Type | EFD |
| Supplier Device Package | - |
| Material | 95 |
| Diameter | - |
| Inductance Factor (Al) | - |
| Tolerance | ±25% |
| Gap | Ungapped |
| Effective Permeability (µe) | - |
| Initial Permeability (µi) | 3000 |
| Core Factor (ΣI/A) mm<sup>-1</sup> | 223 |
| Effective Length (le) mm | 34.4 |
| Effective Area (Ae) mm² | 15.4 |
| Minimum Core Cross Section (Amin) mm² | 12.7 |
| Effective Magnetic Volume (Ve) mm³ | 531 |
| Finish | Uncoated |
| Height | 0.295" (7.50mm) |
| Length | - |
| Width | 0.183" (4.65mm) |
Frequently Asked Questions
8995151521 is a Ferrite Cores manufactured by Fair-Rite Products Corp.. 95 EFD CORE SET
The material of 8995151521 is 95.
The tolerance of 8995151521 is ±25%.
