6578100121
78 EP CORE SET
6578100121 is a Ferrite Cores manufactured by Fair-Rite Products Corp.. 78 EP CORE SET. Key specifications: material 78, tolerance ±25%.
In Stock: 2,016
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Core Type | EP |
| Supplier Device Package | - |
| Material | 78 |
| Diameter | - |
| Inductance Factor (Al) | - |
| Tolerance | ±25% |
| Gap | Ungapped |
| Effective Permeability (µe) | - |
| Initial Permeability (µi) | 2300 |
| Core Factor (ΣI/A) mm<sup>-1</sup> | 168 |
| Effective Length (le) mm | 18.5 |
| Effective Area (Ae) mm² | 11 |
| Minimum Core Cross Section (Amin) mm² | 8.5 |
| Effective Magnetic Volume (Ve) mm³ | 203 |
| Finish | Uncoated |
| Height | - |
| Length | - |
| Width | - |
Frequently Asked Questions
6578100121 is a Ferrite Cores manufactured by Fair-Rite Products Corp.. 78 EP CORE SET
The material of 6578100121 is 78.
The tolerance of 6578100121 is ±25%.
