AC/DC CONVERTER 5V 2X15V 30W
WRT04X-O is a AC DC Converters manufactured by ETA-USA. AC/DC CONVERTER 5V 2X15V 30W. Key specifications: mounting type Chassis Mount, operating temperature -10°C ~ 70°C (With Derating), voltage - input 85 ~ 264 VAC, 125 ~ 370 VDC, size / dimension 4.72" L x 3.20" W x 1.24" H (120.0mm x 81.2mm x 31.5mm).
In Stock: 6
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Number of Outputs | 3 |
| Voltage - Input | 85 ~ 264 VAC, 125 ~ 370 VDC |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 15V |
| Voltage - Output 3 | 15V |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output 1 | 3 A |
| Current - Output 2 | 800 mA |
| Current - Output 3 | 200 mA |
| Current - Output 4 | - |
| Current - Output 5 | - |
| Current - Output 6 | - |
| Power (Watts) | 30W |
| Applications | ITE (Commercial) |
| Voltage - Isolation | 3 kV |
| Efficiency | 71% |
| Operating Temperature | -10°C ~ 70°C (With Derating) |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Size / Dimension | 4.72" L x 3.20" W x 1.24" H (120.0mm x 81.2mm x 31.5mm) |
| Approval Agency | CE, FCC |
| Standard Number | - |
Submit your RFQ for WRT04X-O and get a quote within 24 hours.
