B65879Q0150K095
PQ32/30-N95-DG150
B65879Q0150K095 is a Ferrite Cores manufactured by EPCOS - TDK Electronics. PQ32/30-N95-DG150. Key specifications: supplier device package PQ 32 x 30, material N95, tolerance ±10%.
In Stock: 34
Product Attributes
| Attribute | Value |
|---|---|
| Product Status | Active |
| Core Type | PQ |
| Supplier Device Package | PQ 32 x 30 |
| Material | N95 |
| Diameter | - |
| Inductance Factor (Al) | 150 nH |
| Tolerance | ±10% |
| Gap | Distributed Gapped |
| Effective Permeability (µe) | - |
| Initial Permeability (µi) | 3000 |
| Core Factor (ΣI/A) mm<sup>-1</sup> | 0.441 |
| Effective Length (le) mm | 67.8 |
| Effective Area (Ae) mm² | 153.8 |
| Minimum Core Cross Section (Amin) mm² | 127.5 |
| Effective Magnetic Volume (Ve) mm³ | 10440 |
| Finish | Uncoated |
| Height | 0.597" (15.17mm) |
| Length | 1.260" (32.00mm) |
| Width | 0.866" (22.00mm) |
Frequently Asked Questions
B65879Q0150K095 is a Ferrite Cores manufactured by EPCOS - TDK Electronics. PQ32/30-N95-DG150
The package type of B65879Q0150K095 is PQ 32 x 30.
The material of B65879Q0150K095 is N95.
The tolerance of B65879Q0150K095 is ±10%.
