CAP ALUM 47UF 20% 200V RADIAL
B43821A2476M000 is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 47UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 6,924
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | 4Ohm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 290 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UAS2G470MHD6TN | Nichicon | CAP ALUM 47UF 20% 400V RADIAL | 70% | View |
| EKXL421ELL470ML20S | United Chemi-Con | CAP ALUM 47UF 20% 420V RADIAL TH | 59% | View |
| 50TWL47MEFC8X11.5 | Rubycon | CAP ALUM 47UF 20% 50V RADIAL | 58% | View |
| MAL213829479E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47UF 20% 100V AXIAL | 58% | View |
| 511D476M063CC4D | Vishay Sprague | CAP ALUM 47UF 20% 63V RADIAL | 57% | View |
| 860080372001 | Würth Elektronik | CAP ALUM 47UF 20% 16V RADIAL | 56% | View |
Submit your RFQ for B43821A2476M000 and get a quote within 24 hours.
