CAP ALUM 4700UF 20% 450V SCREW
B43707A5478M600 is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 4700UF 20% 450V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can - Screw Terminals.
In Stock: 5,553
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4700 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 24mOhm @ 100Hz |
| Lifetime @ Temp. | 12000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 13.8 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 40 mOhms |
| Lead Spacing | 1.122" (28.50mm) |
| Size / Dimension | 2.531" Dia (64.30mm) |
| Height - Seated (Max) | 4.693" (119.20mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| E36F451CDN472MDE3U | Chemi-Con | CAP ALUM 4.7MF 20% 450V SCREW CH | 100% | View |
| E37F451CPN472MEA5M | United Chemi-Con | CAP ALUM 4700UF 20% 450V SCREW | 97% | View |
| E33D451CPN472MFA5Q | Chemi-Con | SCREW TERMINAL CAPCITOR | 97% | View |
| B43713A5478M000 | EPCOS - TDK Electronics | CAP ALUM 4700UF 20% 450V SCREW | 96% | View |
| B43455B5478M007 | EPCOS - TDK Electronics | CAP ALUM 4700UF 20% 450V SCREW | 90% | View |
| ALS71C472QH550 | KEMET | CAP ALUM 4700UF 20% 550V SCREW | 78% | View |
Submit your RFQ for B43707A5478M600 and get a quote within 24 hours.
