CAP ALUM 560UF 20% 420V SNAP
B43525B0567M is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 560UF 20% 420V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 420 V, package / case Radial, Can - Snap-In - 4 Lead.
In Stock: 3,366
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 420 V |
| ESR (Equivalent Series Resistance) | 270mOhm @ 100Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.52 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 330 mOhms |
| Lead Spacing | 0.886" (22.50mm) |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 4 Lead |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43525A0567M | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 420V SNAP | 100% | View |
| B43508A5567M87 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 450V SNAP | 92% | View |
| B43508F2567M7 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 250V SNAP | 68% | View |
| B43508A2567M60 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 200V SNAP | 60% | View |
| LGU2C561MELA | Nichicon | CAP ALUM 560UF 20% 160V SNAP | 58% | View |
| 200MXC560MEFC25X30 | Rubycon | CAP ALUM 560UF 20% 200V SNAP | 57% | View |
Submit your RFQ for B43525B0567M and get a quote within 24 hours.
