CAP ALUM 6800UF 20% 400V SCREW
B43464A9688M000 is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 6800UF 20% 400V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 400 V, package / case Radial, Can - Screw Terminals.
In Stock: 3,032
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 18mOhm @ 100Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 17.2 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 23 mOhms |
| Lead Spacing | 1.248" (31.70mm) |
| Size / Dimension | 3.028" Dia (76.90mm) |
| Height - Seated (Max) | 5.677" (144.20mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| E37X401CPN682MEE3M | United Chemi-Con | CAP ALUM 6800UF 20% 400V SCREW | 98% | View |
| LNY2G682MSEGBN | Nichicon | CAP ALUM 6800UF 20% 400V SCREW | 97% | View |
| E32D401CSS682MFE3U | United Chemi-Con | CAP ALUM 6800UF 20% 400V SCREW | 94% | View |
| B43733A9688M000 | EPCOS - TDK Electronics | CAP ALUM 6800UF 20% 400V SCREW | 93% | View |
| ALS80A682QC250 | KEMET | CAP ALUM 6800UF 20% 250V SCREW | 69% | View |
| MAL210129682E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 6800UF 20% 100V SCREW | 54% | View |
Submit your RFQ for B43464A9688M000 and get a quote within 24 hours.
