CAP ALUM 3900UF 20% 450V SCREW
B43464A5398M000 is a Aluminum Electrolytic Capacitors manufactured by EPCOS - TDK Electronics. CAP ALUM 3900UF 20% 450V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 450 V, package / case Radial, Can - Screw Terminals.
In Stock: 9,113
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3900 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 30mOhm @ 100Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 12.2 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 38 mOhms |
| Lead Spacing | 1.122" (28.50mm) |
| Size / Dimension | 2.531" Dia (64.30mm) |
| Height - Seated (Max) | 5.185" (131.70mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| E37X451CPN392MEA5U | United Chemi-Con | CAP ALUM 3900UF 20% 450V SCREW | 100% | View |
| LNU2H392MSEH | Nichicon | CAP ALUM 3900UF 20% 500V SCREW | 95% | View |
| LNY2G392MSEFBB | Nichicon | CAP ALUM 3900UF 20% 400V SCREW | 91% | View |
| E37F501CPN392MEB7U | United Chemi-Con | CAP ALUM 3900UF 20% 500V SCREW | 91% | View |
| E37L501CPN392MFA5U | United Chemi-Con | CAP ALUM 3900UF 20% 500V SCREW | 90% | View |
| LNU2G392MTEG | Nichicon | CAP ALUM 3900UF 20% 400V SCREW | 89% | View |
Submit your RFQ for B43464A5398M000 and get a quote within 24 hours.
