INDUCTORS FOR POWER OVER COAXIAL
ADM32FSC-220M is a Fixed Inductors manufactured by EPCOS - TDK Electronics. INDUCTORS FOR POWER OVER COAXIAL. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C, package / case Horizontal, 4 PC Pad, current rating (amps) 740 mA.
In Stock: 5,958
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Metal |
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 740 mA |
| Current - Saturation (Isat) | 740mA |
| Shielding | Shielded |
| DC Resistance (DCR) | 600mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 33MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -55°C ~ 150°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Horizontal, 4 PC Pad |
| Supplier Device Package | Horizontal, 4 PC Pad |
| Size / Dimension | 0.154" L x 0.098" W (3.90mm x 2.50mm) |
| Height - Seated (Max) | 0.098" (2.50mm) |
Submit your RFQ for ADM32FSC-220M and get a quote within 24 hours.
