FIXED IND 33UH 790MA 476MOHM SMD
MP2A-330-R is a Fixed Inductors manufactured by Eaton - Electronics Division. FIXED IND 33UH 790MA 476MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, package / case Nonstandard, current rating (amps) 790 mA.
In Stock: 9,144
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Molybdenum Permalloy(MPP) |
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 790 mA |
| Current - Saturation (Isat) | 790mA |
| Shielding | Unshielded |
| DC Resistance (DCR) | 476mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.295" L x 0.205" W (7.50mm x 5.20mm) |
| Height - Seated (Max) | 0.071" (1.80mm) |
Submit your RFQ for MP2A-330-R and get a quote within 24 hours.
