ILLUMINATED PUSHBUTTON MAIN SA 1
22-222.011 is a Pushbutton Switches manufactured by EAO. ILLUMINATED PUSHBUTTON MAIN SA 1. Key specifications: mounting type Panel Mount, Front, operating temperature -25°C ~ 85°C, voltage rating - ac 400 V, current rating (amps) 10A (AC).
In Stock: 32
| Attribute | Value |
|---|---|
| Product Status | Active |
| Mounting Type | Panel Mount, Front |
| Type | Standard |
| Circuit | SPST-NC |
| Switch Function | On-Off |
| Current Rating (Amps) | 10A (AC) |
| Voltage Rating - AC | 400 V |
| Voltage Rating - DC | - |
| Actuator Type | Rectangular, Button (Not Included) |
| Actuator Marking | No Marking |
| Color - Actuator/Cap | - |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
| Termination Style | Screw Terminal |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Features | - |
| Panel Cutout Dimensions | Rectangular - 30.00mm x 22.00mm |
| Operating Temperature | -25°C ~ 85°C |
Submit your RFQ for 22-222.011 and get a quote within 24 hours.
