SWITCH TACTILE SPSTX2 0.05A 12V
TL3253BRNBGNF160Q is a Tactile Switches manufactured by E-Switch. SWITCH TACTILE SPSTX2 0.05A 12V. Key specifications: mounting type Through Hole, Right Angle, operating temperature -20°C ~ 70°C, termination style PC Pin, circuit SPST x 2.
In Stock: 2
| Attribute | Value |
|---|---|
| Product Status | Active |
| Circuit | SPST x 2 |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.05A @ 12VDC |
| Actuator Type | Dual |
| Mounting Type | Through Hole, Right Angle |
| Actuator Height off PCB, Vertical | - |
| Actuator Length, Right Angle | 8.55mm |
| Actuator Orientation | Side Actuated |
| Termination Style | PC Pin |
| Outline | 8.40mm x 10.50mm |
| Illumination | Illuminated |
| Illumination Type, Color | LED, Red/Green |
| Illumination Voltage (Nominal) | 1.95, 2.1 VDC |
| Operating Force | 160gf |
| Ingress Protection | - |
| Features | - |
| Operating Temperature | -20°C ~ 70°C |
Submit your RFQ for TL3253BRNBGNF160Q and get a quote within 24 hours.
