MOSFET BVDSS: 25V-30V TSOT26
DMC3060LVT-13 is a Transistors - FETs, MOSFETs - Arrays manufactured by Diodes Incorporated. MOSFET BVDSS: 25V-30V TSOT26. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case SOT-23-6 Thin, TSOT-23-6, power - max 830mW.
In Stock: 6,266
| Attribute | Value |
|---|---|
| Product Status | Active |
| FET Type | N and P-Channel Complementary |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 3.6A (Ta), 2.8A (Ta) |
| Rds On (Max) @ Id, Vgs | 60mOhm @ 3.1A, 10V, 95mOhm @ 2.7A, 10V |
| Vgs(th) (Max) @ Id | 1.8V @ 250µA, 2.1V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 11.3nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 395pF @ 15V, 324pF @ 15V |
| Power - Max | 830mW |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Supplier Device Package | TSOT-23-6 |
Submit your RFQ for DMC3060LVT-13 and get a quote within 24 hours.
