9-36VIN, 12V, 5A, 60W, DIN RAIL
DR24S12005PAFA is a Industrial, DIN Rail Power Supplies manufactured by Delta Electronics. 9-36VIN, 12V, 5A, 60W, DIN RAIL. Key specifications: operating temperature -40°C ~ 85°C (With Derating), current - output (max) 5A, size / dimension 4.67" L x 2.64" W x 0.93" H (118.6mm x 67.1mm x 23.6mm), number of outputs 1.
In Stock: 88
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | DC |
| Number of Outputs | 1 |
| AC Voltage - Input | - |
| DC Voltage - Input (Min) | 9V |
| DC Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 5A |
| Power (Watts) | 60W |
| Voltage - Isolation | 1.5 kV |
| Applications | ITE (Commercial), Railway |
| Efficiency | 92.3% |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Features | Adjustable Output, Remote On/Off |
| Size / Dimension | 4.67" L x 2.64" W x 0.93" H (118.6mm x 67.1mm x 23.6mm) |
| Approval Agency | CE |
| Standard Number | - |
Submit your RFQ for DR24S12005PAFA and get a quote within 24 hours.
