AC/DC CONVERTER 12V 20W
VDRS-20-12 is a Industrial, DIN Rail Power Supplies manufactured by CUI Inc.. AC/DC CONVERTER 12V 20W. Key specifications: operating temperature -20°C ~ 70°C (With Derating), current - output (max) 1.7A, size / dimension 3.90" L x 0.91" W x 3.54" H (99.0mm x 23.0mm x 90.0mm), number of outputs 1.
In Stock: 24
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Input Type | AC |
| Number of Outputs | 1 |
| AC Voltage - Input | 88 ~ 264 VAC |
| DC Voltage - Input (Min) | - |
| DC Voltage - Input (Max) | - |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 1.7A |
| Power (Watts) | 20W |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 83% |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Features | Adjustable Output, Universal Input |
| Size / Dimension | 3.90" L x 0.91" W x 3.54" H (99.0mm x 23.0mm x 90.0mm) |
| Approval Agency | CE, cULus, cURus, TUV |
| Standard Number | - |
Submit your RFQ for VDRS-20-12 and get a quote within 24 hours.
