DC/DC CONVERTER 3.3V +/-15V 30W
PYB30-Q48-T315-U is a DC DC Converters manufactured by CUI Inc.. DC/DC CONVERTER 3.3V +/-15V 30W. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, current - output (max) 3.5A, 500mA, 500mA, size / dimension 2.66" L x 2.16" W x 0.75" H (67.5mm x 55.0mm x 19.1mm).
In Stock: 3
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 75V |
| Number of Outputs | 3 |
| Voltage - Output 1 | 3.3V |
| Voltage - Output 2 | 15V |
| Voltage - Output 3 | -15V |
| Voltage - Output 4 | - |
| Current - Output (Max) | 3.5A, 500mA, 500mA |
| Power (Watts) | 30W |
| Voltage - Isolation | - |
| Applications | - |
| Efficiency | 85% |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Size / Dimension | 2.66" L x 2.16" W x 0.75" H (67.5mm x 55.0mm x 19.1mm) |
| Approval Agency | EN, IEC |
| Standard Number | - |
Submit your RFQ for PYB30-Q48-T315-U and get a quote within 24 hours.
