AC/DC CONVERTER 5V 21W
PSK-S25D-5-DIN is a Industrial, DIN Rail Power Supplies manufactured by CUI Inc.. AC/DC CONVERTER 5V 21W. Key specifications: operating temperature -40°C ~ 85°C (With Derating), current - output (max) 4.1A, size / dimension 2.13" L x 1.44" W x 3.78" H (54.0mm x 36.6mm x 96.1mm), number of outputs 1.
In Stock: 14
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 100V |
| DC Voltage - Input (Max) | 370V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 4.1A |
| Power (Watts) | 21W |
| Voltage - Isolation | 4 kV |
| Applications | ITE (Commercial) |
| Efficiency | 79% |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Features | Adjustable Output, Universal Input |
| Size / Dimension | 2.13" L x 1.44" W x 3.78" H (54.0mm x 36.6mm x 96.1mm) |
| Approval Agency | CB Scheme, IEC, UL |
| Standard Number | 62368-1 |
Submit your RFQ for PSK-S25D-5-DIN and get a quote within 24 hours.
