AC-DC, 45 W, 48 VDC, SINGLE OUTP
PSK-45-48-DIN is a Industrial, DIN Rail Power Supplies manufactured by CUI Inc.. AC-DC, 45 W, 48 VDC, SINGLE OUTP. Key specifications: operating temperature -40°C ~ 70°C (With Derating), current - output (max) 940mA, size / dimension 5.39" L x 2.76" W x 1.49" H (137.0mm x 70.0mm x 37.9mm), number of outputs 1.
In Stock: 10
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 100V |
| DC Voltage - Input (Max) | 370V |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 940mA |
| Power (Watts) | 45W |
| Voltage - Isolation | 4 kV |
| Applications | ITE (Commercial) |
| Efficiency | 87% |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Features | Universal Input |
| Size / Dimension | 5.39" L x 2.76" W x 1.49" H (137.0mm x 70.0mm x 37.9mm) |
| Approval Agency | CE, cURus |
| Standard Number | 62368-1 |
