DC-DC ISOLATED 3K, 1 W, 14.25~15
PRME1-S15-S5-M is a DC DC Converters manufactured by CUI Inc.. DC-DC ISOLATED 3K, 1 W, 14.25~15. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (With Derating), package / case 10-SMD Module, 6 Leads, current - output (max) 200mA.
In Stock: 160
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 14.25V |
| Voltage - Input (Max) | 15.75V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 200mA |
| Power (Watts) | 1 W |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Features | Adjustable Output |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 69% |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD Module, 6 Leads |
| Size / Dimension | 0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | CE |
| Standard Number | 62368-1 |
Submit your RFQ for PRME1-S15-S5-M and get a quote within 24 hours.
