POWER PLUG, 0.6 X 2.9 X 4.5 MM,
PP-063045-OM is a Barrel - Power Connectors manufactured by CUI Devices. POWER PLUG, 0.6 X 2.9 X 4.5 MM,. Key specifications: mounting type Free Hanging (In-Line), voltage - rated 20VDC, termination Solder Eyelet, number of positions/contacts 2 Conductors, 2 Contacts.
In Stock: 442
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Type | Plug |
| Gender | Male |
| Industry Recognized Mating Diameter | 0.60mm ID (0.024"), 3.00mm ID (0.118"), 4.50mm OD (0.177") |
| Actual Diameter | 0.024" (0.60mm ID), 0.177" (4.50mm OD) |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Internal Switch(s) | Does Not Contain Switch |
| Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | - |
| Termination | Solder Eyelet |
| Shielding | Unshielded |
| Features | - |
| Insulation Color | Black |
| Voltage - Rated | 20VDC |
| Current Rating (Amps) | - |
| Mating Length/Depth | 0.476" (12.10mm) |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-2 |
