SPEAKER 8OHM 250MW TOP PORT 86DB
GF0571M is a Speakers manufactured by CUI Devices. SPEAKER 8OHM 250MW TOP PORT 86DB. Key specifications: size / dimension 2.244" Dia (57.00mm), termination Solder Eyelet(s), power - max 500 mW, frequency range 480 Hz ~ 14 kHz.
In Stock: 1,085
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic |
| Type | General Purpose |
| Frequency Range | 480 Hz ~ 14 kHz |
| Frequency - Self Resonant | 480Hz |
| Impedance | 8 Ohms |
| Efficiency - dBA | 86.00 |
| Efficiency - Testing | 250mW/500mm |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Power - Rated | 250 mW |
| Power - Max | 500 mW |
| Port Location | Top |
| Shape | Round |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) |
| Material - Magnet | Ferrite |
| Ingress Protection | - |
| Ratings | - |
| Termination | Solder Eyelet(s) |
| Size / Dimension | 2.244" Dia (57.00mm) |
| Height - Seated (Max) | 0.728" (18.50mm) |
Submit your RFQ for GF0571M and get a quote within 24 hours.
