SPEAKER 57.5X14.85MM ENCLOSED
CES-571423-28PM is a Speakers manufactured by CUI Devices. SPEAKER 57.5X14.85MM ENCLOSED. Key specifications: size / dimension 2.854" L x 0.906" W (72.50mm x 23.00mm), termination Wire Leads, power - max 3 W, frequency range 700 Hz ~ 20 kHz.
In Stock: 47
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic |
| Type | General Purpose, Enclosure Included |
| Frequency Range | 700 Hz ~ 20 kHz |
| Frequency - Self Resonant | 700Hz |
| Impedance | 8 Ohms |
| Efficiency - dBA | 100.00 |
| Efficiency - Testing | 2W/100mm |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Power - Rated | 2 W |
| Power - Max | 3 W |
| Port Location | Top |
| Shape | Rectangular |
| Material - Cone | Cloth |
| Material - Magnet | Nd-Fe-B |
| Ingress Protection | - |
| Ratings | - |
| Termination | Wire Leads |
| Size / Dimension | 2.854" L x 0.906" W (72.50mm x 23.00mm) |
| Height - Seated (Max) | 0.585" (14.86mm) |
Submit your RFQ for CES-571423-28PM and get a quote within 24 hours.
