DC/DC CONVERTER +/-12V 30W
STMGFW302412 is a DC DC Converters manufactured by Cosel USA, Inc.. DC/DC CONVERTER +/-12V 30W. Key specifications: mounting type Chassis Mount, operating temperature -20°C ~ 70°C (With Derating), current - output (max) 1.25A, 1.25A, size / dimension 4.61" L x 2.05" W x 1.06" H (117.1mm x 52.1mm x 26.9mm).
In Stock: 4,808
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Open Frame |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 36V |
| Number of Outputs | 2 |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 1.25A, 1.25A |
| Power (Watts) | 30W |
| Voltage - Isolation | 1.5 kV |
| Applications | ITE (Commercial) |
| Efficiency | 88% |
| Operating Temperature | -20°C ~ 70°C (With Derating) |
| Mounting Type | Chassis Mount |
| Size / Dimension | 4.61" L x 2.05" W x 1.06" H (117.1mm x 52.1mm x 26.9mm) |
| Approval Agency | CE |
| Standard Number | - |
Submit your RFQ for STMGFW302412 and get a quote within 24 hours.
