AC/DC CONVERTER 48V 432W
ADA750F-48 is a AC DC Converters manufactured by Cosel USA, Inc.. AC/DC CONVERTER 48V 432W. Key specifications: mounting type Chassis Mount, operating temperature -10°C ~ 71°C (With Derating), voltage - input 85 ~ 264 VAC, size / dimension 6.91" L x 5.00" W x 2.76" H (175.5mm x 127.0mm x 70.0mm).
In Stock: 274
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 85 ~ 264 VAC |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output 1 | 9 A |
| Current - Output 2 | - |
| Current - Output 3 | - |
| Current - Output 4 | - |
| Current - Output 5 | - |
| Current - Output 6 | - |
| Power (Watts) | 432W (744W Forced Air) |
| Applications | ITE (Commercial) |
| Voltage - Isolation | 3 kV |
| Efficiency | 89% |
| Operating Temperature | -10°C ~ 71°C (With Derating) |
| Features | Adjustable Output, DC Input Capable, PFC, Universal Input |
| Mounting Type | Chassis Mount |
| Size / Dimension | 6.91" L x 5.00" W x 2.76" H (175.5mm x 127.0mm x 70.0mm) |
| Approval Agency | CE, CSA, cURus, TUV, UL |
| Standard Number | 60950-1; 62368-1 |
Submit your RFQ for ADA750F-48 and get a quote within 24 hours.
