AC/DC CONVERTER 36V 450W
ADA750F-36-N1 is a Industrial, DIN Rail Power Supplies manufactured by Cosel USA, Inc.. AC/DC CONVERTER 36V 450W. Key specifications: operating temperature -10°C ~ 71°C (With Derating), current - output (max) 12.5A, size / dimension 6.91" L x 5.00" W x 2.76" H (175.5mm x 127.0mm x 70.0mm), number of outputs 1.
In Stock: 1,931
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | - |
| DC Voltage - Input (Max) | - |
| Voltage - Output 1 | 36V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 12.5A |
| Power (Watts) | 450W (738W Forced Air) |
| Voltage - Isolation | 3 kV |
| Applications | ITE (Commercial) |
| Efficiency | 89% |
| Operating Temperature | -10°C ~ 71°C (With Derating) |
| Features | Adjustable Output, PFC, Universal Input |
| Size / Dimension | 6.91" L x 5.00" W x 2.76" H (175.5mm x 127.0mm x 70.0mm) |
| Approval Agency | CE, CSA, cURus, TUV, UL |
| Standard Number | 60950-1; 62368-1 |
Submit your RFQ for ADA750F-36-N1 and get a quote within 24 hours.
