Cornell Dubilier Electronics (CDE)
CAP ALUM 820UF 20% 200V SNAP
SLP821M200E5P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 820UF 20% 200V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can - Snap-In.
In Stock: 9,694
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 820 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | 243mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.04 A @ 120 Hz |
| Ripple Current @ High Frequency | 3 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.378" (35.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43508B2827M60 | EPCOS - TDK Electronics | CAP ALUM 820UF 20% 200V SNAP | 98% | View |
| LGN2P821MELB35 | Nichicon | CAP ALUM 820UF 20% 220V SNAP | 95% | View |
| LGN2C821MELB25 | Nichicon | CAP ALUM 820UF 20% 160V SNAP | 93% | View |
| B43254E2827M | EPCOS - TDK Electronics | CAP ALUM 820UF 20% 250V SNAP | 88% | View |
| 250MXG820MEFCSN22X60 | Rubycon | CAP ALUM 820UF 20% 250V SNAP | 78% | View |
| EEU-FM1H821L | Panasonic Electronic Components | CAP ALUM 820UF 20% 50V RADIAL | 72% | View |
