Cornell Dubilier Electronics (CDE)
CAP ALUM 47000UF 20% 16V SNAP
SLP473M016H4P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 47000UF 20% 16V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can - Snap-In.
In Stock: 2,885
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 47000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | 14mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 5.5 A @ 120 Hz |
| Ripple Current @ High Frequency | 6.88 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MALIEYH07CC547D42K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47000UF 20% 16V SNAP | 100% | View |
| 16MXG47000MEFCSN35X40 | Rubycon | CAP ALUM 47000UF 20% 16V SNAP | 98% | View |
| EKMH160VSN473MA45U | United Chemi-Con | CAP ALUM 47000UF 20% 16V SNAP | 96% | View |
| EKMH160VSD473MA45U | United Chemi-Con | CAP ALUM 47000UF 20% 16V SNAP | 96% | View |
| 25MXC47000MEFCSN35X50 | Rubycon | CAP ALUM 47000UF 20% 25V SNAP | 82% | View |
| EKMH6R3VSN473MR40U | United Chemi-Con | CAP ALUM 47000UF 20% 6.3V SNAP | 56% | View |
Submit your RFQ for SLP473M016H4P3 and get a quote within 24 hours.
