Cornell Dubilier Electronics (CDE)
CAP ALUM 390UF 20% 250V SNAP
SLP391M250A4P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 390UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 4,518
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | 510mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.49 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.19 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPT2D391MHD | Nichicon | CAP ALUM 390UF 20% 200V RADIAL | 82% | View |
| EKMM451VSN391MA40U | United Chemi-Con | CAP ALUM 390UF 20% 450V SNAP | 81% | View |
| ELXS421VSN391MR40S | United Chemi-Con | CAP ALUM 390UF 20% 420V SNAP | 80% | View |
| EKYB101ELL391MK35S | United Chemi-Con | CAP ALUM 390UF 20% 100V RADIAL | 72% | View |
| ELHS501VSN391MR60S | United Chemi-Con | CAP ALUM 390UF 20% 500V SNAP | 69% | View |
| 420NXG390MEFC30X50 | Rubycon | CAP ALUM 390UF 20% 420V SNAP | 69% | View |
