Cornell Dubilier Electronics (CDE)
CAP ALUM 390UF 20% 200V SNAP
SLP391M200A5P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 390UF 20% 200V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can - Snap-In.
In Stock: 4,439
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | 510mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.35 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.98 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.378" (35.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ELXM201VSN391MQ30S | United Chemi-Con | CAP ALUM 390UF 20% 200V SNAP | 98% | View |
| LGU2F391MELC | Nichicon | CAP ALUM 390UF 20% 315V SNAP | 83% | View |
| 381LQ391M400K032 | Cornell Dubilier Electronics (CDE) | CAP ALUM 390UF 20% 400V SNAP | 78% | View |
| 400VXH390MEFC25X50 | Rubycon | CAP ALUM 390UF 20% 400V SNAP | 63% | View |
| ELXZ500ELL391MJ30S | United Chemi-Con | CAP ALUM 390UF 20% 50V RADIAL | 58% | View |
| EEU-FK1V391L | Panasonic Electronic Components | CAP ALUM 390UF 20% 35V RADIAL TH | 58% | View |
Submit your RFQ for SLP391M200A5P3 and get a quote within 24 hours.
