Cornell Dubilier Electronics (CDE)
CAP ALUM 18000UF 20% 35V SNAP
SLP183M035H7P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 18000UF 20% 35V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can - Snap-In.
In Stock: 5,170
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 18000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | 29mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 4.51 A @ 120 Hz |
| Ripple Current @ High Frequency | 5.64 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.575" (40.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL215847183E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 18000UF 20% 40V SNAP | 89% | View |
| LGY1V183MELC40 | Nichicon | CAP ALUM 18000UF 20% 35V SNAP | 86% | View |
| EKMH500VND183MA63T | United Chemi-Con | CAP ALUM 18000UF 20% 50V SNAP | 86% | View |
| EKMH500VND183MA63U | United Chemi-Con | CAP ALUM 18000UF 20% 50V SNAP | 86% | View |
| EKZN6R3ELL183MMP1S | United Chemi-Con | CAP ALUM 18000UF 20% 6.3V RADIAL | 68% | View |
| 6.3YXS18000MEFC18X35.5 | Rubycon | CAP ALUM 18000UF 20% 6.3V RADIAL | 63% | View |
Submit your RFQ for SLP183M035H7P3 and get a quote within 24 hours.
