Cornell Dubilier Electronics (CDE)
CAP ALUM 15000UF 20% 25V SNAP
SLP153M025E5P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 15000UF 20% 25V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can - Snap-In.
In Stock: 7,162
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 40mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.6 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.5 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.378" (35.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 25MXC15000MEFCSN25X35 | Rubycon | CAP ALUM 15000UF 20% 25V SNAP | 91% | View |
| EKMQ350VSN153MR35S | United Chemi-Con | CAP ALUM 15000UF 20% 35V SNAP | 86% | View |
| EKZN6R3ELL153MMN3S | United Chemi-Con | CAP ALUM 15000UF 20% 6.3V RADIAL | 77% | View |
| EEU-FC0J153 | Panasonic Electronic Components | CAP ALUM 15000UF 20% 6.3V RADIAL | 71% | View |
| 16MXG15000MEFCSN25X30 | Rubycon | CAP ALUM 15000UF 20% 16V SNAP | 70% | View |
| ELXV6R3ELL153MM40S | United Chemi-Con | CAP ALUM 15000UF 20% 6.3V RADIAL | 66% | View |
Submit your RFQ for SLP153M025E5P3 and get a quote within 24 hours.
