Cornell Dubilier Electronics (CDE)
CAP ALUM 1000UF 20% 80V SNAP
SLP102M080A1P3 is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 1000UF 20% 80V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 80 V, package / case Radial, Can - Snap-In.
In Stock: 3,710
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | 332mOhm @ 120Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.19 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.49 A @ 20 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL224691106E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 50V RADIAL | 75% | View |
| UBT1C102MHD8 | Nichicon | CAP ALUM 1000UF 20% 16V RADIAL | 75% | View |
| EY1E102MP51020 | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 72% | View |
| EEU-FM0J102 | Panasonic Electronic Components | CAP ALUM 1000UF 20% 6.3V RADIAL | 71% | View |
| 25ZT1000MG412.5X25 | Rubycon | CAP ALUM 1000UF 20% 25V RADIAL | 68% | View |
| EP1E102MNN1216 | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 61% | View |
Submit your RFQ for SLP102M080A1P3 and get a quote within 24 hours.
