Cornell Dubilier Electronics (CDE)
CAP ALUM 470UF 20% 6.3V RADIAL
SK471M6R3ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 470UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 5,027
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 620mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 380 mA @ 120 Hz |
| Ripple Current @ High Frequency | 418 mA @ 1 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.531" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPW0J471MPD | Nichicon | CAP ALUM 470UF 20% 6.3V RADIAL | 97% | View |
| MAL214265471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 16V RADIAL | 71% | View |
| ESMQ160ELL471MHB5D | United Chemi-Con | CAP ALUM 470UF 20% 16V RADIAL | 64% | View |
| MAL213216471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 25V AXIAL | 59% | View |
| ESK477M025AH1EA | KEMET | CAP ALUM 470UF 20% 25V RADIAL | 56% | View |
| 25RX30470MT810X16 | Rubycon | CAP ALUM 470UF 20% 25V RADIAL | 52% | View |
