Cornell Dubilier Electronics (CDE)
CAP ALUM 100UF 20% 6.3V RADIAL
SK101M6R3ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 100UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 3,783
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 2.92Ohm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 130 mA @ 120 Hz |
| Ripple Current @ High Frequency | 143 mA @ 1 kHz |
| Impedance | - |
| Lead Spacing | 0.079" (2.00mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TVX0J101MAD1LY | Nichicon | CAP ALUM 100UF 20% 6.3V AXIAL | 93% | View |
| USP1A101MDD1TA | Nichicon | CAP ALUM 100UF 20% 10V RADIAL | 79% | View |
| UST1A101MDD1TA | Nichicon | CAP ALUM 100UF 20% 10V RADIAL | 79% | View |
| TVX1A101MAD1LS | Nichicon | CAP ALUM 100UF 20% 10V AXIAL | 79% | View |
| 10YXM100MEFRTA5X11 | Rubycon | CAP ALUM 100UF 20% 10V RADIAL | 75% | View |
| UTS1E101MPD1TD | Nichicon | CAP ALUM 100UF 20% 25V RADIAL | 69% | View |
Submit your RFQ for SK101M6R3ST and get a quote within 24 hours.
