Cornell Dubilier Electronics (CDE)
CAP ALUM 4.7UF 20% 400V RADIAL
SEK4R7M400ST is a Aluminum Electrolytic Capacitors manufactured by Cornell Dubilier Electronics (CDE). CAP ALUM 4.7UF 20% 400V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can.
In Stock: 9,880
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4.7 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 56.47Ohm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 55 mA @ 120 Hz |
| Ripple Current @ High Frequency | 99 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.630" (16.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 475TMA400M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 4.7UF 20% 400V AXIAL | 78% | View |
| EGXE101ELL4R7MH12D | United Chemi-Con | CAP ALUM 4.7UF 20% 100V RADIAL | 71% | View |
| UBT1H4R7MPD8TA | Nichicon | CAP ALUM 4.7UF 20% 50V RADIAL | 69% | View |
| EKMG161ELL4R7MF11D | United Chemi-Con | CAP ALUM 4.7UF 20% 160V RADIAL | 64% | View |
| EV1H4R7MP20511EF4U | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 60% | View |
| MAL214279478E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 4.7UF 20% 100V RADIAL | 55% | View |
Submit your RFQ for SEK4R7M400ST and get a quote within 24 hours.
